Martindale abrasive paper CP918A P400
11-SP VSM-P400

SATRA STM105 RD Worsted Red Discs
11-SF-STM105RD

Martindale abrasive paper KP31B P150
11-SP VSM-P150

YD956 Anti siphon tester
16-YD956

Each other files(Martindale)

SATRA Test Equipment Catalogue [2023-8-1]

SATRA test methods catalogue – June 2011 [2023-8-1]

Adidas Lab Procedure Manual Contents [2023-8-1]

Quality Assured Consumables [2023-8-1]

All products

Test materials

Other test materials

View information :


Item :	11-M RD-165-J
Name :	Worsted Rep Discs for Martindale tester RD
Price :	$290.91/bag (100 pcs)
	Your Quantity: x
Brand :	UK James H.Heal
Spec. :	diameter 165mm, Min 195g/m²
Summary :	Worsted Rep Discs for Martindale tester described in this paper complies with the property requirements specified in SATRA TM31, EN ISO 12947-1
Views :	8558 Date : 2023-8-1

Description :

100 % Recommended

diameter 165mm, or according client's specification
Min 195g/m²
Minimum mass per unit area = 195g/m², 165mm diameter

Worsted Rep Discs for Martindale tester described in this paper complies with the property requirements specified in SATRA TM31, EN ISO 12947-1

	Warp	Weft
Yarn linear density	R63.tex/2	R74.tex/2
Thread per unit length	1.75±0.10/mm	1.35±0.10/mm
Singles twist	540±20 tpm “Z”	500±20 tpm "Z"
Twofold twist	450±20 tpm “S”	350±20 tpm "S"
Fibre diameter	27.5±2μm	29±2μm
